HIGH TEMPERATURE SLEEVE

HTG Fiberglass Sleeve

ZBAO HTG Fiberglass Sleeve is kind of insulation sleeve, which braided by E grade glass fiber then weave lock by impregnated with special resin.
  • item no.:

    ZBAO-HTG-FS
  • lead time:

    3 days
  • product orgin:

    China
  • brand:

    ZBAO-CHINA
  • shipping port:

    Shanghai,Ningbo
  • color:

    White,blue,black,red,green,etc
  • MOQ:

    100 meters
  • products details

HTG fiberglass sleeve



1.Product Introduction

ZBAO HTG Fiberglass Sleeve is kind of insulation fire sleeve, which braided by E grade glass fiber then weave lock by impregnated with special resin. Widely used to protect wires from high temperature and occasional flame on electric motor, household appliances and automobile.



2.Product Characters

Thermal Class

C

Size/Inner diameter

1mm-30mm

Colour

White.Other colors can be customized

Working temperature

-70°C -550°C

Breakdown voltage

1kv

Character

High temperature & flame resistant,anti-aging,acid and alkali resistant.



3.Standard Specifications

ZBAO Part No.

Inner Dia./mm

Thickness /mm

Roll Length/m

Nominal

Tolerance

ZBHTG-S-010

1

+0.30

-0.0

0.30±0.12

Min Packing 100m/roll

MOQ:5000m

ZBHTG-S-015

1.5

ZBHTG-S-020

2

0.40±0.15

ZBHTG-S-025

2.5

ZBHTG-S-030

3

Min Packing 100m/roll

MOQ:3000m

ZBHTG-S-040

4

ZBHTG-S-050

5

+0.5

-0.0

0.45±0.15

ZBHTG-S-060

6

ZBHTG-S-070

7

ZBHTG-S-080

8

ZBHTG-S-090

9

+1.0

-0.0

0.60±0.20

ZBHTG-S-100

10

Min Packing 50m/roll

MOQ:2000m

ZBHTG-S-120

12

ZBHTG-S-130

13

ZBHTG-S-140

14

Min Packing 25m/roll

MOQ:1000m

ZBHTG-S-160

16

HTHTG-S-180

18

+2.0

-0.0

0.64±0.22

Min Packing 20m/roll

MOQ:1000m

HTHTG-S-200

20

HTHTG-S-220

22

HTHTG-S-250

25

Min Packing 20m/roll

MOQ:1000m

HTHTG-S-300

30

0.66±0.22



We are professional fire sleeve manufacturer,we have participated in the fierce market competition and won our customers support and trust with qualified product quality, preferential product price and satisfactory sales service.

Looking forward to cooperation with you
